CYP600500300
Cytech
Battery
IP 55, NEMA 3R, NEMA 3S
Pole Mount
2 Fans
19inch
12U
Product Description
| Name | Technical Parameter |
| External Size | H*W*D=600*500*300mm (23.62 × 19.69 × 11.81 inch) |
| Enclosure layout | One compartment, for installing 19 inch equipment |
| Enclosure material | Single layer galvanized steel sheet |
| Security design | Embedded door, embedded hinges, 2-point security lock |
| Protection level | IP55 / NEMA 3R / NEMA 3S |
| Color | RAL7035 |
| Climate control | DC48V fan |
| Lighting system | Door sensor+48V LED light(door open, the LED will light on; door closed, the LED will go out.) |
| Grounding system | 200A Copper bar(13 point M6 and 2 point M8) |
| Working temperature | - 40 ℃ ~ + 55 ℃ |
| Working Humidity | ≤ 95% (+ 40 ℃) |
| Air Pressure | 62kpa ~ 106kpa (similar to 0m ~ 5000m altitude) |
Note：The air conditioner can also choose AC 110V 60HZ or DC 48V, and the fan can also choose AC 110V or 220V.
Includes: locking door with air conditioner,19inch rackmount rails,floormount plinth or hardwares.
| Name | Quantity | Unit | Technical parameter |
| Outdoor server rack enclosure | 1 | set | H*W*D=600*500*300mm (23.62 × 19.69 × 11.81 inch) |
| Fan | 1 | set | DC48V with temperature control |
| LED Lamp | 1 | set | DC48V,used for illumination in the enclosure |
| Grounding bus bar | 1 | set | 200A Copper bar(13 point M6 and 2 point M8) |
| Equipment supporting | 1 | set | |
| Package | 1 | set | Wooden box , wooden pallet+stretch film or wooden pallet +wooden box |
The following accessories are available for optional ordering.
| Item | Technical parameter | Picture |
| EMS | 19 inch environment monitoring unit 1U; DC48V, support RS232,RS485, SNMP,TCP/IP communication protocol. 1× smoke sensor, 1× water sensor, 1× temperature sensor, 1× door sensor.
Environmental monitoring system is a comprehensive network of devices and technologies designed to track and assess various aspects of the environment. This system plays a crucial role in gathering data to understand environmental conditions, detect changes, and manage natural resources. |
|
| Fire Extinguisher | Hot aerosol fire extinguishing device is a new, efficient and environment-friendly fire fighting product with Vanguard International Semiconductor Corporation level, which is the first in China. It is a high-tech green fire protection product that benefits humanity, born under the background of the International Montreal Agreement and China's increased awareness of environmental protection. It is an ideal substitute for halon fire extinguishing devices and is suitable for relatively enclosed spaces such as distribution cabinets.
Electric or hot start: Hot start temperature ≥170℃; Electric start temperature ≥700mA. |
|
| Wiring type PDU | AC input：63A/2P*2 with interlock； AC/SPD：30-60KA/2P*1； AC output：63A/1P*1,32A/1P*1，16A/1P*3，3 holes Maintenance socket*1 |
|
| Integrated PDU | Can be customized according to customer requirements. |
|
| Rectifier | AC220V/110V transfer to DC48V, Connect the battery as a backup power,also can be customized according to customer requirements. |
|
ODF | Optic Distribution Frame (ODF) is a critical component in a fiber optic network infrastructure. It serves as a centralized point for the termination, organization, and distribution of fiber optic cables. The primary purpose of a distribution frame is to facilitate efficient and organized connectivity, making it easier to manage, troubleshoot, and expand the network.
Function: 1)Termination Point; 2)Organization and Management; 3)Splicing Trays; 4)Labeling and Documentation; 5)Security and Protection; 6)Scalability;
Can be customized according to customer requirements. |
|
| Backup battery | Can be lithium battery or lead acid battery. |
Options
| Model | Height | Type | Rate | Color | H*W*D | Climate Control | Application |
CY800650650 | Floor stand | IP55 | Grey | 800mm*650mm*650mm | Air conditioner 500W DC48V fan | Telecom Wireless/Broadband Solar-based installation | |
CY1050650650 | Floor stand | IP55 | Grey | 1050mm*650mm*650mm | Air conditioner 500W DC48V fan | Telecom Wireless/Broadband Solar-based installation | |
CY1400800800 | Floor stand | IP55 | Grey | 1400mm*800mm*800mm | Air conditioner 500W DC48V fan | Telecom Wireless/Broadband Solar-based installation | |
CY1600800800 | Floor stand | IP55 | Grey | 1600mm*800mm*800mm | Air conditioner 1000W DC48V fan | Telecom Wireless/Broadband Solar-based installation | |
CY1700750750 | Floor stand | IP55 | Grey | 1700mm*700mm*700mm | Air conditioner 1000W DC48V fan | Telecom Wireless/Broadband Solar-based installation | |
CY2100900900 | Floor stand | IP55 | Grey | 2100mm*900mm*900mm | Air conditioner 1500W DC48V fan | Telecom Wireless/Broadband Solar-based installation |
Other size to be continued ,please send us inquiry for futher discussion
Name | Specification |
AC220V 50HZ | |
AC220V 60HZ | |
AC110V 60HZ / DC48V | |
Cooling capacity from 300W-5000W | |
DC48V | |
40W/K-200W/K | |
AC220V 50HZ & DC48V | |
1500W&80W/K | |
DC48V | |
200W-1200W | |
AC220V 50HZ | |
AC220V 60HZ | |
AC110V 60HZ / DC48V |
Flexibility
(1) Material of pole mount solar battery box enclosure can be Constructed of durable, galvanized steel,sandwich panel ,stainless steel SS304,aluminium.
(2) Front and side access doors allow technicians access to equipment storage areas and cable routing.
(3) Customized color ,standard color RAL7035,other color acceptable based on appointed color code.
(4) Wide range of thermal management options for even the most demanding heat dissipation needs allows for optimization of thermal performance and reduced energy costs.
(5) The cooling solution adopted compressed air conditioner ,TEC (Thermoelectric Cooler),Hex (heat exchanger),Fans,Combined AC&HEX.
(6) Offers a wide range of configuration options providing maximum flexibility including PDU, rectifier ,integrated AC-DC power systems.
(7) Silk screening Logo and environmental friendly painting artwork for outdoor telecom cabinet.
(8) Offers all kinds environment sensors,including doors,smoke,temperature sensors.
(9) Remote monitoring system supported, communication protocol is RS232/RS485/SNMP.
How to order
◆ Acceptable temperature range for your equipment;
◆ Heat load of equipment;
◆ The highest local ambient temperature；
◆ Noise Level；
◆ Future Expansion；
By carefully considering these factors, you can select a enclosure climate control system that meets the specific needs of your equipment and environmental conditions.
(1) If conditions permit, try to install the Large Pole Mount Enclosure Rack Outdoor 12U in a cool and ventilated place with clean surrounding environment .
(2) After the cable construction is completed, please make sure to seal the gap around the cable with the sealant provided randomly in the cabinet, so as to avoid the condensation caused by moisture entering and affecting the use performance of the equipment.
(3) The grounding bar of the enclosure must be reliably grounded, and the grounding resistance to the ground shall be less than 10 Ω .
(4) Please clean the ventilation and dust screen in the enclosure regularly every month. According to the actual situation, the period of cleaning dust screen can be shortened or extended properly.
Outdoor pole‑mount equipment enclosures—especially a Large Pole Mount Enclosure Rack Outdoor 12U—are engineered to safeguard critical IT and power systems in the harshest environments. A robust IP55 outdoor enclosure or NEMA enclosure pole mount ensures protection against dust, water jets, temperature extremes, and vandalism—making them ideal for a wide range of mission‑critical applications.
Remote Cell Towers: Houses radios, routers, and power supplies in a compact Large Pole Mount Enclosure, guaranteeing uptime in off‑grid sites. A Rack Outdoor 12U design maximizes space for networking gear and battery backup.
Base Transceiver Stations (BTS): An IP55 outdoor enclosure protects transceivers, rectifiers, and battery backups from moisture and dust ingress, meeting stringent telco reliability standards.
Outdoor Surveillance Systems: DVRs/NVRs and PoE switches live inside a Large Pole Mount Enclosure Rack Outdoor 12U, ensuring uninterrupted recording and remote access even under heavy rain or dust storms.
Traffic Monitoring: Encases cameras, edge‑compute nodes, and data loggers in a NEMA enclosure pole mount, supporting 24/7 operation at intersections and highways.
Smart Grid Infrastructure: Secures RTUs, communication gateways, and PLCs within a certified IP55 outdoor enclosure, enabling reliable grid monitoring and load balancing. A Rack Outdoor 12U layout provides standardized mounting for all control modules.
Renewable Energy Plants: A pole‑mount battery enclosure—or Large Pole Mount Enclosure—protects energy‑storage batteries, charge controllers, and telemetry equipment in solar farms and wind turbine sites.
Railway Control Systems: Deploys outdoor pole‑mount enclosures along tracks to shield signalling equipment and wireless access points from vandalism and weather extremes. A Rack Outdoor 12U footprint fits neatly on trackside poles.
Roadside Traffic Management: Houses traffic‑signal controllers, loop detectors, and communication modules in a NEMA enclosure pole mount, ensuring safe and efficient traffic flow.
Field Communications: A rugged equipment enclosure outdoor, in a Large Pole Mount Enclosure format, secures satellite terminals, tactical radios, and computing gear in forward‑deployed outposts.
Remote Monitoring Stations: Utilizes IP55 outdoor enclosures for ISR (Intelligence, Surveillance, Reconnaissance) sensors and power systems in austere environments, with all components organized in a Rack Outdoor 12U setup.
Industrial Automation: Protects PLCs, HMIs, and network switches in outdoor processing plants, ensuring continuous control of pumps, conveyors, and mixers. A Large Pole Mount Enclosure Rack Outdoor 12U delivers a standardized rack for streamlined wiring and maintenance.
Oil & Gas Sites: A pole‑mount battery enclosure shelters SCADA nodes, gas‑detection systems, and communication repeaters against corrosive atmospheres.
Disaster Recovery: Rapid‑deploy outdoor pole‑mount enclosures host satellite uplinks, VoIP gateways, and battery backups in relief camps. A Rack Outdoor 12U design ensures all critical equipment is rack‑mounted and ready to go.
Mobile Command Centers: Integrates UPS units and network racks inside NEMA enclosure pole mount assemblies for seamless command‑and‑control in field operations, leveraging the space‑saving benefits of a Large Pole Mount Enclosure.
Space‑Efficient Design: Compact footprint ideal for poles and slim towers.
High Protection Rating: IP55/NEMA 3R or higher resists rain, dust, and tampering.
Versatile Mounting: Universal clamps and brackets fit a wide range of pole diameters.
Battery Integration: Dedicated battery trays and ventilation for safe energy storage.
By selecting a certified equipment enclosure outdoor—whether an IP55 outdoor enclosure, NEMA enclosure pole mount, Large Pole Mount Enclosure, or specialized pole‑mount battery enclosure in a Rack Outdoor 12U format—you ensure maximum uptime, ease of maintenance, and long‑term reliability across all your outdoor deployments.
