1500W Outdoor Control Cabinet Air Conditioner 5100BTU

1500W Outdoor Control Cabinet Air Conditioner 5100BTU Product Video

1500W Outdoor Control Cabinet Air Conditioner 5100BTU Certificate

1500W Outdoor Control Cabinet Air Conditioner 5100BTU Introduction

Outdoor control cabinet air conditioner or control panel ac is actively cooling by compressor ,it will remove the heat inside the cabinet to outside. It also can keep the dust and heat outside the cabinet,avoiding problems from using fan. The temperature inside the cabinet can be maintained at an ideal temperature for electrical components which effectively guarantee the stability of the electronic equipment and improves the reliability of the whole system.

1500W Outdoor Control Cabinet Air Conditioner 5100BTU Specifications

1.Technical parameter of Control Cabinet Air Conditioner

Note:@L35/L35 is Internal temperature 35℃, ambient temperature 35℃

2. Thermal cycle and air flow of Outdoor Control Cabinet Air Conditioner

Outdoor Control Cabinet Air Conditioner Cooling princple : the high-pressure refrigerant liquid in the system enters the evaporator and evaporates to absorb heat of the air in the cabinet, so the air is cooled, and the refrigerant that evaporates into gas in the evaporator is inhaled by the compressor and compressed into the high-pressure and high-temperature refrigerant gas, which enters the condenser and cooled to refrigerant liquid, and then re-enters the evaporator to cool the indoor air, and circulates accordingly.

1500W Outdoor Control Cabinet Air Conditioner 5100BTU Features

◆Control Cabinet Air Conditioner also can keep the dust and heat outside the cabinet,avoiding problems from using fan;

◆The temperature inside the cabinet can be maintained at an ideal temperature for electrical components which effectively guarantee the stability of the electronic equipment and improves the reliability of the whole system;

◆Compact structure ,reasonable design and easy maintenance;

◆Digital temperature controller and high precision of temperature control;

◆The heating function and the hydrogen function is optional;

◆Remote measuring, remote communication, remote control, which can realize multiple automatic protection and comprehensive self-testing function;

◆Dry contact alarm output,NO/NC optional;

◆LED display, all the settings can changed at the field

◆Multiple self-protection design & visible monitoring interface, RS485 communication port (MODBUS-RTU);

◆Fit for harsh condition (T3), R134a refrigerant .

1500W Outdoor Control Cabinet Air Conditioner 5100BTU Flexibility

Cooling capacity ranges from 300w to 5000w

Voltage range :AC220V 50HZ,AC220V 60HZ,60HZ , AC110V60HZ ,DC48V

Widely used for outdoor telecom cabinets ,battery cabinets,elecric cabinets and industry control cabinets etc.

Remote monitoring system supported, communication protocol is RS485

More option for 1500W Outdoor Control Cabinet Air Conditioner 5100BTU

1.220VAC 50HZ power outdoor control cabinet air conditioner

2. 220VAC 60HZ power outdoor control cabinet air conditioner

3.110V 60HZ power outdoor control cabinet air conditioner

Other Outdoor Control Cabinet Air Conditioner

How to Choose the Right Outdoor Control Cabinet Air Conditioner

Selecting the appropriate Outdoor Control Cabinet Air Conditioner (industrial control panel air conditioner) is crucial for ensuring the optimal performance of your electrical equipment. By focusing on key factors, you can choose a system that meets your cooling needs efficiently.

1. Acceptable Temperature Range for Your Equipment

The industrial panel AC must maintain the internal temperature of the cabinet within the equipment's optimal operating range to prevent overheating and damage.

2. Heat Load of Equipment

Calculate the total heat generated by the equipment. The Outdoor Control Cabinet Air Conditioner must match the heat load to avoid inefficient cooling or system failure.

3. Highest Local Ambient Temperature

Ensure the industrial control panel air conditioner can handle the highest ambient temperature expected in your environment, particularly in harsh outdoor settings.

4. Noise Level

Consider the noise produced by the industrial panel air conditioner. For quieter environments, ensure the system operates within an acceptable noise range.

5. Future Expansion

Plan for future system growth. Choose an Outdoor Control Cabinet Air Conditioner with scalability to accommodate increased heat load as your equipment expands.

By evaluating these factors, you can select a cabinet climate control system that aligns with your equipment and environmental conditions.

Normative Standards for Outdoor Control Cabinet Air Conditioner

To ensure safety and efficiency, the industrial panel AC should comply with the following standards:

• GB 4208 – Enclosure Protection Class

• GB 4706.1 – Safety of Electrical Appliances

• GB 9237-2001 – Refrigerating System Safety

• GB/T 17626.8 – Electromagnetic Compatibility

These standards ensure the Outdoor Control Cabinet Air Conditioner operates effectively and safely.

Fault Analysis and Solutions

1. Cabinet Temperature Too High, Air Conditioner Not Working

• Causes: Power failure, incorrect cooling temperature

• Solutions: Check power supply, adjust cooling temperature, contact professional maintenance.

2. Poor Cooling Effect

• Causes: Mismatched cooling capacity, high ambient temperature

• Solutions: Choose a larger unit, ensure correct operating range, contact maintenance.

3. Machine Stopping Suddenly

• Causes: Cabinet temperature too high

• Solutions: Adjust cooling temperature, consult maintenance.

Warranty for Outdoor Control Cabinet Air Conditioner

The Outdoor Control Cabinet Air Conditioner typically has a 12 to 18-month warranty, covering manufacturing defects. Warranty does not cover:

• Out of warranty period

• Improper installation or abnormal conditions

• Damage from external factors

By following proper maintenance guidelines, you can ensure reliable operation throughout the warranty period.

By considering these factors, you can confidently choose the best Outdoor Control Cabinet Air Conditioner for your needs, ensuring efficient and long-term performance.
